• BRITON 5740 DIN Latch Case 60mm Backset Square 5740.60.S.SS - Satin Nickel
  • BRITON 5740 DIN Latch Case 60mm Backset Radius 5740.60.R.SS - Satin Nickel
  • BRITON 5740 DIN Latch Case 60mm Backset
  • BRITON 5740 DIN Latch Case 60mm Backset
  • BRITON 5740 DIN Latch Case 60mm Backset
1 4

Brand: Briton

BRITON 5740 DIN Latch Case 60mm Backset

BRITON 5740 DIN Latch Case 60mm Backset

£47.67
£0.00 £47.67
Sale Sold out

By purchasing you are agreeing to our Terms of Sale.

Low stock: 8 left

Style

The Briton 5740 is a DIN standard latch lock for use on doors using lever furniture which are not required to be locked. It has a 60mm backset with 72mm centres and a profiled latch which is reversible. The 5740 latchlock has been fire tested to EN 1634-1 for use on fire doors up to 1hr timber / 4hr steel when used with the appropriate intumescent kit (Briton 5000.IP).

BRITON 5740 DIN Latch Case 60mm Backset

Features

  • Grade 316 stainless steel single piece round or square forend
  • Galvanised steel lockcase with satin nickel plating for corrosion resistance
  • Quick reversible latch
  • Centres 72mm
  • Backset: 60mm
  • Profiled latch and forend

Finishes

  • Satin Nickel

Categories

  • Locking Product
  • Mortice Locks & Latches
  • Latches
  • Mortice

Our BRITON 5740 DIN Latch Case 60mm Backset from Briton is a quality tested product at a reasonably low price.

If you need any further information or are looking for an alternative size or similar item please contact us.

Option Specifications
Backset 60mm
Case Finish Satin Nickel
Case Height 165mm
Case Depth 89mm
Forend Length 235mm
Forend Width 20mm
Handed Reversible
Mechanism Latch Only
Pack Quantity 1
Standards CE Marked,BS EN 12209:2003
Product References L32973, L32972
Barcode References 5050640042071, 5050640042088
* Information above is accurate at the time of entry and may be subject to change at any time.
